Gazelle UltimateC380
Price $5,399
A city bike and touring bike in one with a 500Wh integrated battery
Ultimate C380
Frame shape
Low-Step
Number of gears
Stepless
Price $5,399
Craftsmanship
With over 130 years of expertise, we know precisely what we're doing. Creating bicycles that you can rely on. What begins with a design comes together in our factory. Where we work everyday to create the perfect Gazelle for you.
Discover the Ultimate
)
"I purchased this bike for my wife last year. It enabled her to ride with me and she easily rode way ahead of me on long steep climbs."
John
Battery and range
Platina
- Watt-hours500 Wh
- Capacity13,5 Ah
- Battery charging time with 2A7 h 30 m
- Battery charging time with 4A4 h 30 m
- Battery positionintergrated in the frame
- Battery brandBosch
- Battery modelIntube
- Battery voltage36V
- Eco80 mi
- Tour50 mi
- Sport35 mi
- Turbo30 mi
Platina
Watt-hours
500 Wh
Capacity
13,5 Ah
Battery charging time with 2A
7 h 30 m
Battery charging time with 4A
4 h 30 m
Battery position
intergrated in the frame
Battery brand
Bosch
Battery model
Intube
Battery voltage
36V
Eco
80 mi
Tour
50 mi
Sport
35 mi
Turbo
30 mi
)
Specifications
- Color
- Light olive gloss, mallard blue mat, mallard blue matte
- Fork suspension
- Mono Integrated
- Bike weight description
- Excl. battery
- Weight (kg)
- 24.8 kgs
- Weight
- 24.8 excl. accu, 24.8 excl. battery
- Color
- Light olive gloss, mallard blue mat, mallard blue matte
- Bike Max. Total Weight (kg)
- 130
- Sitting Position
- Active
- Frame description
- Stable aluminium frame with 70,5° headset angle and 71,5° saddle tube angle for sporty cycling characteristics. Battery, motor and cables harmoniously integrated into the frame. High-quality finish with attention to detail.
- Frame material
- Aluminum
- Cockpit Cable Integration
- Yes
- Frame shape
- Low-Step
- Frame Size CM
- 46, 53, 57
- Fork description
- Aluminium, binnenbalhoofd vering, lichtgewicht
- Fork Material
- Aluminum
- Fork suspension
- Mono Integrated
Frame
Fork
- Front wheel
- 55
- Rear wheel
- 24
- Front rim
- Ryde Dutch, Double-walled aluminium for extra strong and efficient cycling performance, Ryde Dutch, Dubbelwandig aluminium voor extra sterkte en goede rij-eigenschappen
- Rear rim
- Ryde Dutch, Double-walled aluminium for extra strong and efficient cycling performance, Ryde Dutch, Dubbelwandig aluminium voor extra sterkte en goede rij-eigenschappen
- Front hub
- Shimano
- Rear hub
- Enviolo Trekking Manual, continuously variable gears, Enviolo Trekking Manual, traploos versnellingssysteem
- WheelSize Front
- 28"
- Wheels Tire Front Etrto
- 47-622
- Front tire
- Schwalbe Energizer Plus
- Rear tire
- Schwalbe Energizer Plus
- Wheels Tire Front Description
- Schwalbe Energizer Plus
Wheels
Tires
- Brand shifters
- Enviolo
- Front chainwheel
- 55
- Gear Type
- Hub
- Number of gears
- Stepless
- Drivetrain
- Belt
- Crankset Model
- Delta
- Crankset description
- Miranda Delta
- Front Brake Type
- Hydraulic disc brake
- Brake sytem code
- SE
- Front Brake Brand
- Shimano
- Primary Rear Brake Model
- BR-MT420
- Front brake
- Shimano BR-MT420, 180 mm
- Rear brake
- Shimano BR-MT420, 160 mm
Gears
Transmission
Brakes
- Handlebar
- Gazelle Aero leather, Kunststof handvatten met ergonomische vorm voor betere verdeling van druk op de handen, Gazelle Aero leather, Plastic handlebar grips with ergonomic form for a better distribution of pressure on the hands
- Stem adjustable
- Yes
- pim_productsteerlock
- Yes
- Cockpit Handlebar Grip Brand
- Gazelle
- Saddle
- Selle Royal Loire
Handlebar
Seat
- Front light
- AXA Blue Line 50
- Front Light Energy Source
- Battery
- Front Light Lux
- 50
- Rear Light Energy Source
- Battery
- Rear light
- Herrmans H-Cargo
Front light
Rear light
- Motor
- Bosch Performance Line
- System Model
- Performance Line
- Ebike System Brand
- Bosch
- Ebike Engine Position
- Mid
- Ebike Max Speed mph
- 20
- Engine Max Torque (Nm)
- 65
- Charger
- Bosch
- Ebike Battery Charger Description
- 4 Ah
- Battery Position
- Intergrated in the frame
- Display
- Bosch Purion
- Ebike Walk Assist
- Yes
- Display Type
- LCD
Motor
Battery
Display
- Frame warranty
- 10 year's warranty
- Fork warranty
- 5 year's warranty
- Paint warranty
- 5 year's warranty
- Other parts warranty
- 2 year's warranty
- Battery warranty
- 2 year's warranty
- Motor warranty
- 2 year's warranty
- Display warranty
- 2 year's warranty
Garantie
- Lock
- Axa
- Lock brand
- Axa
- ART classification
- ART**
- Kickstand
- Ursus Mooi
- pim_productchaincase
- Yes
- Rear carrier description
- Aluminum
- Rear carrier max load (kg)
- 25
- Rear carrier
- Yes
Lock
Other
Luggage rack
